StarTech.com PCI Express to 2 Port USB 3.1 Type-C Controller Card with UASP
PCI-Express 1x controller card with 2 USB 3.1 Type-C ports
Pictures may differ from actual products
This USB 3.1 PCIe card was designed by StarTech.com. It fits into a free PCI-Express slot on your computer and allows you to upgrade your current system by adding two USB-C ports (10 Gbit/s).
PCI-Express 1x controller card with 2 USB 3.1 Type-C ports
Overview
StarTech.com
Add 2 USB 3.1 Type C (10 Gb/s) ports for your PCI Express compatible PC
This USB 3.1 PCIe card was designed by StarTech.com. It installs into a free PCI-Express slot on your computer and allows you to upgrade your current system by adding two USB-C (10 Gbps) ports. Faster USB performance: Adds two 10Gbps USB Type-C ports to your computer.
Featuring an ASMedia ASM3142 chipset, this card takes full advantage of the speed of USB 3.1 Gen 2 technology. Supporting higher data rates, this USB 3.1 Gen 2 PCIe expansion card is essential for external drives and many other USB 3.1 devices. The card is backward compatible with USB 3.0 (5 Gbps) and USB 2.0 (480 Mbps) devices. The card works with the new USB-C devices, but can easily support your existing USB-A devices with inexpensive USB Type-C cables and adapters. See our Accessories tab for supported options.
Easy installation: The USB 3.1 card is compatible with Windows, Linux and MacOS operating systems. In addition, the card includes standard and half-height brackets for easy installation in computers and servers of various sizes.
Features:
- Adds 2 external USB 3.1 ports with UASP support
- Supports transfer speeds up to 10 Gb/s
- Complies with PCI Express 3.0 x4specifications
- 2-port USB PCIe card with ASMedia ASM3142 controller (PCIe 3.0 x4), 2x SuperSpeed USB-A 10 Gb/s (USB 3.1 Gen 2 / USB 3.2 Gen 2x1); max. 10 Gb/s throughput per port
- Expansion card supports Multiple INs, to maintain maximum speed with mixed speed devices, and UASP
- Optimised for SSD/HDD, NVMe and USB drives; compatible with USB 3.0/2.0
- Power: USB 3.0 PCI Express expansion card with SATA power socket provides additional power to USB ports of up to 4.5W (5V @ 0.9A) per USB-C port
- Compatibility: USB PCIe card installs in a full/half height PCIe 3.0 x4 slot
- Mounting bracket included
- Backward compatible with PCIe 2.0
- Supports Win/Linux/macOS with automatic drivers on Windows 8 and later
Specifications
Select your criteria
General information |
Product name |
StarTech.com PCI Express to 2 Port USB 3.1 Type-C Controller Card with UASP |
Brand |
StarTech.com | |
Model |
PEXUSB312C3 | |
Technical specifications |
Bus |
PCI Express 3.0 x4 |
Controllers |
USB 3.1 | |
Connector(s) |
2 X USB 3.1 | |
Supported OS |
Windows 2003 Server | |
| Windows Vista | ||
| Linux 2.6 | ||
| Windows Server 2008 R2 | ||
| Microsoft Windows 7 | ||
| Microsoft Windows 8 | ||
| Microsoft Windows 8.1 | ||
| Microsoft Windows 10 | ||
| Microsoft Windows 11 | ||
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
Product referenced on 7 Mar 2022
