Aten CE8220
HDMI HDBaseT 2.0 USB KVM Extension System (4K 100m)
Last price 1 099€94
Holy Moly!
Equivalent products suggestions:
Overview
Aten
Enjoy high quality 4K HDMI video signals up to 100 m
Aten's CE820 HDMI HDBaseT 2.0 USB KVM extender incorporates the latest HDBaseT 2.0 technologies to deliver 4K HDMI video, stereo audio, USB, Ethernet and RS-232 signals up to 100 meters (330 feet) using a single Cat 6/2L-2910 Cat 6 cable. HDBaseT 2.0 provides the most reliable transmission on the market as well as long-range capability that extends Full HD 1080P signals up to 150 metres. With easy cable installation supporting a variety of signals, the CE820 is ideal for applications where convenient remote access is needed - such as transportation control centres, medical facilities, industrial warehouses and extended workstations.
Features:
- Supports HDBaseT 2.0 technology
- Extends video, audio, USB, RS-232 and Ethernet signals over a single Cat 6/6a/2L-2910 Cat 6 cable
- Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
- Status detection and LED indication for HDBaseT signal transmission to the remote unit
- EDID buffer for smooth start-up and highest quality display
- HDMI (3D, Deep Color, 1080P, 4K); HDCP 2.2 compatible
- Superior video quality over long distance
- Standard HDBaseT mode up to 4K at 100m (Cat 6/6a / 2L-2910)
- HDBaseT long range mode up to 1080P at 150m
- Long range mode switch - switches between standard and long range HDBaseT modes in a snap
- Supports individual 2-channel stereo audio ports and full-speed USB 2.0
- Supports PC Wake-up function via a single push-button through the RS-232 channel
- Built-in ESD protection 8 KV/15 KV (contact voltage 8 KV; air voltage 15 KV)
- Console ports: 1 x HDMI female (Black) / 3 x USB Type A female / 1 x Stereo Mini Jack female (Green) / 1 x Stereo Mini Jack female (Pink) / 1 x RJ-45 female (Black)
- KVM Ports: 1 x HDMI female (Black) / 1 x USB Type B female (White) / 1 x Stereo Mini Jack female (Green) / 1 x Stereo Mini Jack female (Pink) / 1 x RJ-45 female (Black)
- RS-232: 1 x DB-9 female (Black) / 1 x DB-9 male (Black)
- Power: 1 x DC plug with lock / 1 x DC plug with lock
- Unit to unit: 1 x RJ-45 female (Black)/ 1 x RJ-45 female (Black)
- Dimensions (L x W x H) : 18.20 x 12.19 x 2.87 cm / 18.20 x 12.19 x 2.87 cm
- Weight : 0.63 Kg / 0.65 Kg
Specifications
Select your criteria
General information |
Product name |
Aten CE8220 |
Brand |
Aten | |
Model |
CE820-AT-G | |
Technical specifications |
Product type |
KVM switch |
Connector(s) |
4 X 2.5mm Jack Female Stereo | |
| 1 X DB-9 Female | ||
| 1 X DB-9 Male | ||
| 2 X RJ45 Female | ||
| 2 X USB Type A Female | ||
Rackable |
No | |
Video output(s) |
HDMI | |
Peripheral input(s) |
USB | |
Network port (RJ45) |
Yes | |
Audio function |
Yes | |
Warranties |
Commercial warranty |
Seller 2 years |
Legal warranty |
See terms & conditions |
See all Aten products
See Aten KVM section
Product referenced on 14 Oct 2020
