Dexlan 1U dual rail rackmount server console (DX1804-VUP2)

1U rackmount server console with 18.5" TFT screen - 4 port KVM with 4 VGA-USB cables supplied - French AZERTY keyboard with touchpad

Pictures may differ from actual products

This Dexlan 19" rackmount KVM console has a French keyboard (optionally replaceable with a Qwerty keyboard) and a touchpad pointing device, as well as a high-resolution TFT-LCD screen with a diagonal measurement of 18.5".

1U rackmount server console with 18.5" TFT screen - 4 port KVM with 4 VGA-USB cables supplied - French AZERTY keyboard with touchpad

Overview

The console you need for your installation


This Dexlan 19" rackmount KVM console has a French keyboard (replaceable by a Qwerty keyboard as an option) and a touchpad type pointing device, as well as a high resolution TFT-LCD screen with a diagonal of 18.5". The console is the same thickness as a network switch (1U), saving space in your computer cabinet or rack.

Its integrated KVM switch allows you to control 4 computers connected using the 4 combined keyboard-mouse cords supplied with the unit. In addition to the Dexlan LCD console, it is possible to connect another USB keyboard/mouse set to the 2 rear ports of the KVM. In addition, a specific slot is provided for an Ethernet IP module in order to remotely control the console and the servers connected to the 4 ports of the KVM switch, via the local network or the Internet.

Main features :
  • Switching: Push button / OSD menu
  • Keyboard: 105-key USB type (QWERTY) removable without tools (Qwerty US/UK/DE optional)
  • Pointing: 2-button TouchPad
  • Indicators : Power - CPU online
  • Buttons : Power - OSD menu - CPU 1 to 4
  • 18.5" diagonal Full HD TFT-LCD screen
  • LCD resolution: 1366 x 768 at 60 Hz
  • External power supply: 12 volts 4A
  • Compatible with 19'' rack, 800 to 1200mm deep (requires rear posts)
  • Supplied with 19" front and rear rack mounting brackets
  • Includes 4 x 1.80m VGA-USB cables
  • Compatible with IP remote control module
  • Multi-platform: Windows 2000/XP/Vista/7/8/8.1/10, MacOS 10.6 and above, Linux, Unix...
  • Dimensions : 446 x 630 x 42 mm
  • Weight : 19 kg
Specifications
Select your criteria

General information

Product name

Dexlan 1U dual rail rackmount server console (DX1804-VUP2)

Brand

Dexlan

Model

DX1804-VUP2

Technical specifications

Product type

Console

Number of computers

4

Number of cable kits supplied

4

Rackable

Yes

Video output(s)

VGA

Peripheral input(s)

PS/2 + USB

Audio function

No

Warranties

Commercial warranty

Seller 3 years

Legal warranty

See terms & conditions

Product referenced on 30 Nov 2022
