ASUS NUC 13 Pro RNUC13ANHi3 (90AR00C1-M00010).
Intel Core i3-1315U Intel UHD Graphics Wi-Fi 6E / Bluetooth 5.3 + LAN 2.5 GbE + M.2 slots (without display/memory/storage/system).
Pictures may differ from actual products
The ASUS NUC 13 Pro RNUC13ANHi3 is a barebone PC featuring a powerful 13th-generation Intel Core i3 processor. It supports up to 64 GB DDR4 RAM and M.2 PCIe NVMe SSDs; it also has a 2.5" hard drive bay.
Intel Core i3-1315U Intel UHD Graphics Wi-Fi 6E / Bluetooth 5.3 + LAN 2.5 GbE + M.2 slots (without display/memory/storage/system).
All the power of a standard PC in the palm of your hand
TheASUS NUC 13 Pro RNUC13ANHi3 is a barebone PC featuring a powerful 13th-generation Intel Core i3 processor, support for up to 64 GB DDR4 RAM and M.2 PCIe NVMe SSDs, and a 2.5" hard drive bay. Ultra-compact and easy to integrate, it will easily find its place in the office or at home. Supplied without RAM or hard drive, it will enable you to design a high-performance customised Mini PC with ease.
Intel Core performance
Thanks to its 13th-generation Intel Core processor, the Intel NUC offers both remarkable performance and low energy consumption. 13th-generation Intel Core processors are packed with advanced features designed to improve productivity and entertainment quality. With a 2.5-inch hard drive bay, an SSD slot in M.2 PCIe format (2282), another in M.2 SATA format (2242) and two RAM slots (max. 64 GB), this NUC PC offers smooth, fast operation.
Uncompromisingly compact
The NUC Arena Canyon from ASUS has a compact format that allows it to be installed in a wide range of environments. Its reduced size doesn't prevent it from performing well for office and multimedia use, thanks to its Intel Core processor and its numerous connectivity options. When it comes to connectivity, it has nothing to envy from larger PCs. It has 2 Thunderbolt 4 ports, 3 USB 3.1 ports and 2 HDMI 2.0b ports.
Available disk slots :
- 1x PCI-E 4.0 4x M.2 disk slot (M.2 2280 compatible)
- 1x M.2 PCI-E 3.0 1x/SATA 6 Gbps drive slot (M.2 2242 compatible)
- 1x 2.5" SATA 6 Gbps drive slot
Select your criteria
General information |
Product name |
ASUS NUC 13 Pro RNUC13ANHi3 (90AR00C1-M00010). |
Brand |
ASUS | |
Model |
90AR00C1-M00010 | |
Processor and chipset |
Integrated processor |
Yes |
Processor |
Intel Core i3 | |
CPU frequency |
4.5 GHz | |
Processor support |
N/A | |
Number of CPUs supported |
1 | |
Memory |
Memory format |
2 X SO-DIMM 260-pin (DDR4) |
Memory Frequency(ies) |
DDR4 3200 MHz | |
Memory type |
DDR4 | |
Memory technology |
Dual Channel | |
Dual Channel |
Yes | |
Maximum RAM capacity per slot |
32 GB | |
Maximum RAM capacity |
64 GB | |
Graphic |
Integrated graphics controller |
Yes |
Graphics chipset |
Intel UHD Graphics | |
Expansion slots |
Graphic connector(s) |
None |
Graphic card max. length |
0 mm | |
Number and Type of slots |
None | |
Storage |
Hard drives connectors |
1 X Serial ATA |
| 1 X M.2 - PCI-E 4.0 x4 | ||
| 1 X M.2 PCI-E x1 + SATA 6Gb/s | ||
M.2 support |
1 X M.2 2280 | |
| 1 X M.2 2242 | ||
Optical drive type |
None | |
Audio |
Audio Chipset |
Integrated |
Network |
Number of ports/Ethernet controler |
1 X Intel i226-V |
Network standard(s) |
2.5 Gbps Gigabit Ethernet (2.5 GbE) | |
Wireless network standard(s) |
Bluetooth 5.3 | |
| Wi-Fi 6E | ||
Connectivity |
Front panel connectors |
2 X USB 3.1 |
| 1 X 3.5mm Jack Female Stereo | ||
Rear panel connectors |
1 X USB 3.1 | |
| 2 X HDMI Female | ||
| 2 X Thunderbolt 4/USB-C | ||
| 1 X USB 2.0 | ||
| 1 X RJ45 Female | ||
Case |
Number of 2.5" slots |
1 |
Power |
120 W | |
Compatibility |
Supported OS |
Ubuntu Linux |
| Windows 11 | ||
| Windows 10 | ||
| Red Hat Linux | ||
Physical characteristics |
Barebone format |
ITX |
Width |
117 mm | |
Height |
54 mm | |
Depth |
112 mm | |
Weight |
750 g | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
See all ASUS products
Product referenced on 25 Apr 2024
