ASUS NUC 15 Pro RNUC15CRHC700002
Intel Core 7 240H Intel Graphics Wi-Fi 7 / Bluetooth 5.4 + LAN 2.5 GbE + M.2 PCIe 5.0 slot (without display/memory/storage/system)
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
ASUS Mini PC with Intel Core processor
TheASUS NUC 15 Pro offers first-rate performance thanks to the Intel Core processor family. It is designed for office and multimedia tasks, offering a reduced size and easy consumption. The ASUS NUC 15 Pro features an innovative articulated lever design that allows quick and convenient RAM or storage upgrades.
Highlights
- Leverages Wi-Fi sensing to ensure instant wireless network availability while reducing power consumption
- Support for up to 4 displays via 2 HDMI 2.1 outputs and 2 USB-C/Thunderbolt 4 ports
- Tool-free access to the chassis, making upgrades quick and easy.
- Compact case weighs less than a litre and takes up minimal space.
- Advanced thermal design with dual heat pipes and strategically placed air intakes
Technical specifications
- Intel Core 7 240H (6 Performance-Cores 2.5 GHz / 5.2 GHz Turbo + 4 Efficient-Cores 1.8 GHz / 4.0 GHz Turbo - 16 Threads - 24 MB Cache)
- 2 DDR5 SO-Dimm 5600 MHz RAM slots (96 GB max.)
- M.2 2280 PCIe 5.0 x4 slot + M.2 2242 PCIe 4.0 x4 slot
- Wi-Fi 7 + Bluetooth 5.4
- 2.5 GbE LAN
- 2 USB 3.1 + 1 USB-C 3.2 20 Gbps on front panel
Select your criteria
General information |
Product name |
ASUS NUC 15 Pro RNUC15CRHC700002 |
Brand |
ASUS | |
Model |
90AR00Q2-M00040 | |
Processor and chipset |
Integrated processor |
Yes |
Processor |
Intel Core 7 | |
CPU frequency |
5.2 GHz | |
Processor support |
N/A | |
Number of CPUs supported |
1 | |
Memory |
Memory format |
2 X SO-DIMM 262-pin (DDR5) |
Memory Frequency(ies) |
DDR5 5600 MHz | |
Memory type |
DDR5 | |
Memory technology |
Dual Channel | |
Dual Channel |
Yes | |
Maximum RAM capacity per slot |
48 GB | |
Maximum RAM capacity |
96 GB | |
Graphic |
Integrated graphics controller |
Yes |
Graphics chipset |
Intel Graphics | |
Expansion slots |
Graphic connector(s) |
None |
Graphic card max. length |
0 mm | |
Number and Type of slots |
None | |
Storage |
Hard drives connectors |
1 X M.2 - PCI-E 5.0 x4 |
| 1 X M.2 - PCI-E 4.0 x4 | ||
M.2 support |
1 X M.2 2280 | |
| 1 X M.2 2242 | ||
Optical drive type |
None | |
Audio |
Audio Chipset |
Integrated |
Network |
Number of ports/Ethernet controler |
Intel i226-V |
Network standard(s) |
2.5 Gbps Gigabit Ethernet (2.5 GbE) | |
Wireless network standard(s) |
Bluetooth 5.4 | |
| Wi-Fi 7 | ||
Connectivity |
Front panel connectors |
1 X USB 3.2 Type C |
| 2 X USB 3.1 | ||
Rear panel connectors |
2 X Thunderbolt 4/USB-C | |
| 2 X HDMI Female | ||
| 1 X USB 3.1 | ||
| 1 X USB 2.0 | ||
| 1 X RJ45 Female | ||
Case |
Power |
120 W |
Compatibility |
Supported OS |
Microsoft Windows 11 |
Max CPU TDP |
45 W | |
Physical characteristics |
Barebone format |
ITX |
Width |
117 mm | |
Height |
54 mm | |
Depth |
112 mm | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
ASUS Computer GmbH |
Postal address |
Harkort STR. 21-23, 40880 RATINGEN, GERMANY | |
Electronic Address |
ProducSafety@asus.com |
See all ASUS products
Product referenced on 3 Jun 2025
