ASUS NUC 15 Pro RNUC15CRKV500002
Intel Core Ultra 5 235H vPro Intel Arc Graphics Wi-Fi 7 / Bluetooth 5.4 + LAN 2.5 GbE + M.2 PCIe 5.0 slot (without display/memory/storage/system)
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
ASUS Mini PC with AI-powered Intel Core Ultra processor
TheASUS NUC 15 Pro delivers industry-leading performance thanks to the Intel Core Ultra processor family, and thanks to three AI engines (GPU, NPU and CPU) it is able to meet the AI challenges of today and tomorrow while maintaining low power consumption. The ASUS NUC 15 Pro has been designed to handle the most demanding workloads.
Highlights
- AI Ready : Takes advantage of all three AI engines; Intel Core Ultra CPU, Intel Arc Graphics GPU and AI Boost NPU.
- Supports up to 4 displays via 2 HDMI 2.1 outputs and 2 USB-C/Thunderbolt 4 ports
- Tool-free chassis access, making upgrades quick and easy.
- Compact case weighs less than a litre and takes up minimal space.
- Advanced thermal design with dual heat pipes and strategically placed air intakes
Technical specifications
- Intel Core Ultra 5 235H (4 Performance-Cores 2.4 GHz / 5.0 GHz Turbo + 8 Efficient-Cores 1.8 GHz / 4.4 GHz Turbo + 2 Low-Power Core 0.7 GHz / 2.5 GHz Turbo - 14 Threads - 18 MB Cache)
- Intel AI Boost (OpenVINO, WindowsML, DirectML, ONNX RT)
- 2 DDR5 SO-Dimm 5600 MHz RAM slots (96 GB max.)
- M.2 2280 PCIe 5.0 x4 slot + M.2 2242 PCIe 4.0 x4 slot
- Wi-Fi 7 + Bluetooth 5.4
- 2.5 GbE LAN
- 2 USB 3.1 + 1 USB-C 3.2 20 Gbps on front panel
Select your criteria
General information |
Product name |
ASUS NUC 15 Pro RNUC15CRKV500002 |
Brand |
ASUS | |
Model |
90AR00R2-M000M0 | |
Processor and chipset |
Integrated processor |
Yes |
Processor |
Intel Core Ultra 5 | |
CPU frequency |
5 GHz | |
Processor support |
N/A | |
Number of CPUs supported |
1 | |
AI Ready |
Yes | |
Memory |
Memory format |
2 X SO-DIMM 262-pin (DDR5) |
Memory Frequency(ies) |
DDR5 5600 MHz | |
Memory type |
DDR5 | |
Memory technology |
Dual Channel | |
Dual Channel |
Yes | |
Maximum RAM capacity per slot |
48 GB | |
Maximum RAM capacity |
96 GB | |
Graphic |
Integrated graphics controller |
Yes |
Graphics chipset |
Intel Arc Graphics 140T | |
Expansion slots |
Graphic connector(s) |
None |
Graphic card max. length |
0 mm | |
Number and Type of slots |
None | |
Storage |
Hard drives connectors |
1 X M.2 - PCI-E 5.0 x4 |
| 1 X M.2 - PCI-E 4.0 x4 | ||
M.2 support |
1 X M.2 2280 | |
| 1 X M.2 2242 | ||
Optical drive type |
None | |
Audio |
Audio Chipset |
Integrated |
Network |
Number of ports/Ethernet controler |
Intel i226-V |
Network standard(s) |
2.5 Gbps Gigabit Ethernet (2.5 GbE) | |
Wireless network standard(s) |
Wi-Fi 7 | |
| Bluetooth 5.4 | ||
Connectivity |
Front panel connectors |
2 X USB 3.1 |
| 1 X USB 3.2 Type C | ||
Rear panel connectors |
2 X HDMI Female | |
| 1 X USB 3.1 | ||
| 2 X Thunderbolt 4/USB-C | ||
| 1 X USB 2.0 | ||
| 1 X RJ45 Female | ||
Case |
Power |
120 W |
Compatibility |
Supported OS |
Microsoft Windows 11 |
Max CPU TDP |
28 W | |
Physical characteristics |
Barebone format |
ITX |
Width |
117 mm | |
Height |
37 mm | |
Depth |
117 mm | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
ASUS Computer GmbH |
Postal address |
Harkort STR. 21-23, 40880 RATINGEN, GERMANY | |
Electronic Address |
ProducSafety@asus.com |
