QNAP QSW-M408-2C

8-port Gigabit LAN manageable web switch 4 x 10 GbE/SFP combo ports

Pictures may differ from actual products

The QSW-M408-2C is a manageable Layer 2 web switch that offers 8 Gigabit LAN ports, 2 SFP /10GbE combo ports and 2 SFP ddis ports. The QSW-M408-2C is configured via the easy-to-use QNAP Web Swith System (QSS) interface.

8-port Gigabit LAN manageable web switch 4 x 10 GbE/SFP combo ports

Overview

Manageable Layer 2 Web Switch with four SFP+ 10GbE ports (2 combo)

The QNAP QSW-M408-2C is a manageable Layer 2 web switch that offers 8 Gigabit LAN ports, 2 SFP+ ports and 2 SFP+/10GbE combo ports. The QSW-M408-2C is configured via the easy-to-use QNAP Web Swith System (QSS) interface.

With its compact and modern design, the QSW-M408-2C fits perfectly with other devices in the modern digital office. Featuring a design with a delicate white textured surface, the QSW-M408-2C helps users easily identify each port. The flexible DC power connector also allows the QSW-M408-2C to be universally deployed. Being fully plug-and-play, you simply connect the QSW-M408-2C to your devices and it will do the rest.

Flexible deployment

The QSW-M408-2C provides four 10GbE SFP+ ports (with two 10GbE SFP+/RJ45 combo ports) and eight Gigabit ports to connect different devices and establish high-speed hybrid networks. With SFP+ interfaces, it is possible to use DAC (direct attach copper) cables to connect directly to SFP+ devices. Also, you can use 10G-SFP-T copper transceiver modules to connect 10GBASE-T/NBASE-T devices via Category 6, 5 or 5e RJ45 cabling. The capacity of the QSW-M408-2C is 96 Gbps, which guarantees the full potential of each port.

QSS Dashboard

The QSW-M408-2C uses the QNAP Switch System (QSS) with an easy-to-use web-based graphical user interface (GUI) full of value-added features to simplify network configuration and management.

The QSW-M408-2C provides bandwidth and packet control functions (including LACP, VLAN, QoS, and IGMP Snooping) to boost network performance through IP bundling and bandwidth management. It also has powerful system and security features (including ACL, LLDP, RSTP, and Flow Control) to help administrators improve network reliability through access controls, troubleshooting, loop prevention, and avoiding packet loss.

Specifications
Select your criteria

General information

Product name

QNAP QSW-M408-2C

Brand

QNAP

Model

QSW-M408-2C

Technical specifications

Number of ports

12

Network standard(s)

10 Gbps Gigabit Ethernet (10 GbE)
10/100/1000 Mbps

Number of 10/100/1000 Mbps ports

8

Number of GBIC ports

2

Number of SFP combo (RJ45/Fiber) ports

2

Rackable

No

Manageable

Yes

Administration level

Level 2

SNMP

No

PoE (Power over Ethernet)

No

Width

290 mm

Depth

127 mm

Height

42.5 mm

Weight

1.15 kg

Consumption

22.04 W

Warranties

Commercial warranty

Seller 3 years

Legal warranty

See terms & conditions

Product referenced on 6 Jul 2020

Customer reviews
Global rating
10/10
based on 2 reviews Editorial and moderation guide
  • 100%
    2 reviews
  • 0%
  • 0%
  • 0%
  • 0%
  • by PhilGourgand
    Posted on 22 Apr 2022
    Product bought from LDLC on 25 Mar 2022
    Number of reviews: 1 Average rating: 10

    Very good Multi-gig switch

    Hello,
    I've been using it for a while now, but it's a little bit too small for me to be able to use it.
    I've been using it for a while now, but I'm not sure if it's a good idea to put it in a closet or on a desk.
    I recommend to place it in a cupboard but not on a desk.

    It works with a freebox pro in SFP+ without problem if you have a compatible cable
    the distribution works particularly well in 1GbE, 2.5GbE and 10GbE.
    50% pro and 50% personal use (teleworker)

    Only small drawback, the software
    I've been using it for a while now, but it's not easy to get used to, and in my opinion it lacks a bit of customisation (renaming ports)
    I've been using it for a while now, but it's a good idea to keep it up to date!

    Review automatically translated
  • by AlexandreF
    Posted on 31 Oct 2021
    Product bought from LDLC on 25 Aug 2020
    Number of reviews: 1 Average rating: 10

    Works very well with a Freebox Delta when coupled with good cables

    For this switch to work well with a Freebox Delta, you really need to design a 10GB network. This requires connecting the Freebox and the switch with an optical adapter (avoid DACs that consume too much power).
    Contrary to my previous opinion, the switch works well but the SFP+ connectors are very... temperamental. And the model is innocent.

    Review automatically translated
