Jonsbo D31 MESH Black
Mini Tour case with tempered glass panel and Mesh front panel
Pictures may differ from actual products
The Jonsbo D31 MESH is a superb compact PC case with a simple, elegant design. Well thought-out and well designed, it can easily accommodate all types of configuration (multimedia, gaming, office automation, etc.). It can accommodate the most powerful components on the market.
Mini Tour case with tempered glass panel and Mesh front panel
-
Yes
-
No
-
Yes
-
No
-
Mid tower
-
Mini tower
Compact, simple and ultra-efficient case
The Jonsbo D31 MESH is a superb compact PC case with a simple, elegant design. Well thought-out and well designed, it can easily accommodate all types of configuration (multimedia, gaming, office automation, etc.). It can accommodate the most powerful components on the market, as well as up to 8 fans. Compatible with AIO watercooling for processors (120/240/280/360 mm) and equipped with a transparent panel and perforated front panel (Mesh), it will be perfect for assembling a modern PC with a sober design.
Jonsbo D31 MESH Black
- Mini Tower case 205 x 440 x 363 mm (Volume: 32L)
- Mesh front panel
- Compatible with Micro ATX, Mini ITX, DTX motherboards
- Chassis material: 0.6/0.7 mm steel
- Drive bays: 2 x 2.5" + 1 x 3.5
- Fan slots: 2x 120 mm or 3x 140 mm on top, 2x 120 mm or 3x 140 mm underneath, 1x 120 mm front, 1x 120 mm rear
- Compatible with 120/240/280/360 mm AIO radiators
- Graphics card compatible up to 330 mm / 400 mm (depending on configuration)
- Front connectors: 1x USB-C 3.1, 1x USB 3.0, 1x 3.5 mm jack
Select your criteria
General information |
Product name |
Jonsbo D31 MESH Black |
Brand |
Jonsbo | |
Model |
D31 MESH BLACK | |
Main characteristics |
Graphic card max. length |
330 mm |
Max height CPU fan |
168 mm | |
Power format |
ATX/EPS | |
Case format |
Mini tower | |
Use |
Media Center | |
| Gamer | ||
| Office | ||
Material |
Steel | |
| Tempered glass | ||
Motherboard format |
Micro ATX | |
| Mini ITX | ||
| DTX | ||
Power supply supplied |
No | |
Design |
Case color |
Black |
Front color |
Black | |
Dust filters |
1 | |
Integrated display |
No | |
Mesh front |
Yes | |
Glass |
Yes | |
Tempered glass |
Yes | |
LED RGB |
No | |
ARGB LED |
No | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Standard connectors (on the motherboard) | |
Expansion slots |
Number of PCI slots |
4 |
Low profile |
No | |
Number of invisible 3.5" slots |
1 | |
Number of 2.5" slots |
2 | |
Front connectivity |
Location of expansion ports |
Front |
Connector(s) available |
1 X 3.5mm Jack Female Stereo | |
| 1 X USB 3.1 Type C | ||
| 1 X USB 3.0 | ||
Cooling |
Number of rear fan(s) slots |
1 X 120mm |
Quantity of rear fan(s) supplied |
0 | |
Number of front fan(s) slots |
1 X 120mm | |
Quantity of front fan(s) supplied |
0 | |
Number of above fan(s) slots |
2 X 120 or 140mm | |
| 1 X 120mm | ||
Quantity of above fan(s) supplied |
0 | |
Number of underneath fan(s) slots |
1 X 120mm | |
| 2 X 120 or 140mm | ||
Quantity of underneath fan(s) supplied |
0 | |
Water cooling |
AIO radiator compatibility |
240mm radiator |
| 120mm radiator | ||
| 280mm radiator | ||
| 360mm radiator | ||
Above AIO slot(s) |
240mm radiator | |
| 280mm radiator | ||
| 360mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
Physical characteristics |
Width |
205 mm |
Height |
363 mm | |
Depth |
440 mm | |
Weight |
5.9 kg | |
Volume |
32 l | |
Warranties |
Commercial warranty |
Seller 3 years |
Legal warranty |
See terms & conditions |
