Jonsbo D500 Silver
Grand Tour case with tempered glass side window
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
Practical and elegant large tower case
Discover the JONSBO D500 case, a high-end model in a large tower format designed to accommodate the most ambitious configurations. With its generous dimensions (250 × 586 × 620 mm), sturdy steel and aluminium structure and side window, this case combines strength, elegance and scalability. Compatible with ITX, Micro-ATX, ATX and EATX motherboard formats, it offers total flexibility in component integration, whether for a high-end gaming configuration or a powerful workstation.
Advantages of the Jonsbo D500 case
- Grand Tour case: 250 x 586 x 620 mm
- Compatible with E-ATX, ATX, Micro ATX and Mini ITX motherboards
- Chassis materials: 0.8 mm steel + 2 mm aluminium
- SSD/HDD bays: 11x 2.5" or 10x 3.5"
- 3 fans included (2x 120 mm at the front and 1x 140 mm at the rear)
- Compatible with 240/360/420 mm and 120 mm (rear) AIO radiators
- Compatible with graphics cards up to 480 mm (or 340 mm, depending on the hardware installed)
- CPU cooler up to 190 mm in height
- 8 PCI slots + 3 vertical PCI slots for vertical graphics card installation (PCI riser not included)
Select your criteria
General information |
Product name |
Jonsbo D500 Silver |
Brand |
Jonsbo | |
Model |
D500 SILVER | |
Main characteristics |
Graphic card max. length |
480 mm |
Max height CPU fan |
190 mm | |
Power supply max. length |
220 mm | |
Power format |
ATX/EPS | |
Case format |
Full tower | |
Use |
Gamer | |
Material |
Tempered glass | |
| Steel/Aluminum | ||
Motherboard format |
ATX | |
| Micro ATX | ||
| Mini ITX | ||
| E-ATX | ||
Power supply supplied |
No | |
Design |
Case color |
Silver |
Front color |
Silver | |
Dust filters |
2 | |
Integrated display |
No | |
Mesh front |
Yes | |
Glass |
Yes | |
Tempered glass |
Yes | |
Fish tank (panoramic view) |
No | |
LED RGB |
No | |
ARGB LED |
No | |
Water cooling compatible |
Yes | |
Motherboard connector location |
Standard connectors (on the motherboard) | |
Expansion slots |
Number of PCI slots |
11 |
Low profile |
No | |
Number of 2.5" slots |
1 | |
Number of 2.5"/3.5" slots |
10 | |
Number of visible 5.25" slots |
0 | |
Front connectivity |
Location of expansion ports |
Front |
Connector(s) available |
2 X USB 3.0 | |
| 1 X USB 3.1 Type C | ||
| 1 X 3.5mm Jack Female Stereo | ||
Cooling |
Fan(s) included |
No |
Number of rear fan(s) slots |
1 X 120 or 140mm | |
Quantity of rear fan(s) supplied |
1 | |
Number of front fan(s) slots |
2 X 120 or 140mm | |
| 1 X 120mm | ||
Quantity of front fan(s) supplied |
2 | |
Number of above fan(s) slots |
3 X 120 or 140mm | |
Quantity of above fan(s) supplied |
0 | |
Number of underneath fan(s) slots |
2 X 120mm | |
Quantity of underneath fan(s) supplied |
0 | |
Water cooling |
AIO radiator compatibility |
240mm radiator |
| 120mm radiator | ||
| 360mm radiator | ||
| 420mm radiator | ||
Front AIO slot(s) |
240mm radiator | |
| 360mm radiator | ||
| 420mm radiator | ||
Above AIO slot(s) |
240mm radiator | |
| 360mm radiator | ||
| 420mm radiator | ||
Rear AIO slot(s) |
120mm radiator | |
Physical characteristics |
Width |
250 mm |
Height |
586 mm | |
Depth |
620 mm | |
Weight |
17.5 kg | |
Volume |
90 l | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
Caseking GmbH |
Postal address |
Logistikcenter Gaußstraße 1 10589 Berlin, Allemagne (UE) | |
Electronic Address |
info@caseking.de |
See all Jonsbo products
Product referenced on 2 Feb 2026
