ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC

20 GB GDDR6 - HDMI/Tri-DisplayPort - PCI Express (AMD Radeon RX 7900 XT)

Pictures may differ from actual products

Based on the RDNA 3 architecture, the ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC graphics card is designed for 4K UHD gaming. Powerful and efficient, it will delight gamers and creative minds looking for a high-performance, innovative graphics solution.

20 GB GDDR6 - HDMI/Tri-DisplayPort - PCI Express (AMD Radeon RX 7900 XT)

Overview

Gaming in 4K UHD and more

Based on theRDNA 3 architecture, the ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC graphics card is designed for 4K UHD gaming. Powerful and efficient, it will delight gamers and creative minds looking for a high-performance, innovative graphics solution. Cutting-edge technologies such as AMD Radeon Super Resolution, AMD Smart Access Memory, AMD Radeon Boost, AMD FreeSync and AMD Radeon Anti-Lag give you ultra-smooth games with spectacular graphics.

ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC

The ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC graphics card features integrated aRGB LEDs that are Polychrome SYNC compatible. It also incorporates a metal frame to reinforce the structure of the graphics card and prevent the risk of bending.

AMD RDNA 3

AMD RDNA 3 is AMD's revolutionary new gaming architecture. It enables AMD Radeon RX 7900 XT graphics cards to deliver next-generation performance, visuals and efficiency in 4K and beyond.
  • 84 Computing Units
  • 84 Ray Accelerators
  • 192 ROPS
  • 5376 Stream Processors
  • 6 Shader Engines

Cutting-edge technologies

  • AMD FidelityFX Super Resolution: (FSR) uses advanced scaling technologies to boost your frame rates in certain titles1 and deliver a high-quality, high-performance gaming experience.
  • AMD Radeon Super Resolution: boosts performance on thousands of games.
  • AMD Smart Access Memory: full access from CPU to GPU memory for enhanced gaming performance.
  • AMD FreeSync technology: eliminates screen tearing without jerkiness or latency.
  • AMD Radeon Anti-Lag: even faster click response times
  • AMD Software Radeon Image Sharpening: uses a contrast-adaptive sharpening algorithm that restores clarity to in-game visuals that may have been smoothed by other effects, bringing out the detail in objects

Powerful software suite

AMD Radeon Software Adrenalin 2022 Edition drivers enhance your gaming experience. Designed to give you a clean, modern, easy-to-use interface where you can quickly access the latest software features, game stats, performance reports, driver updates, and more - all in one place for ease of use. Take advantage of the ALT+R shortcut to open AMD Software: Adrenalin Edition directly in-game, making it even easier and more convenient to tweak your favourite features.

Specifications
Select your criteria

General information

Product name

ASRock AMD Radeon RX 7900 XT Phantom Gaming White 20GB OC

Brand

ASRock

Model

RX7900XT PGW 20GO

Graphics chipset

Graphics chipset

AMD Radeon RX 7900 XT

GPU brand

AMD

Chipset frequency

2075 MHz

Boosted frequency

2450 MHz

Overclocked

Yes

Number of GPU

1

Bus

PCI Express 4.0 x16

Memory

Video memory size

20 GB

Memory interface

320 bit(s)

Video memory frequency

20000 MHz

Memory type

GDDR6

Architecture

Stream processors

5376

Direct X support (version)

12

Technical specifications

Multi-GPU

None

Display

Optimal in-game resolution

Up to 4K

HD Ready

Yes

4K UHD resolution(s)

Yes

VR Ready (virtual reality)

Yes

VirtualLink compatible

No

Connectivity

Video outputs

1 X HDMI Female
3 X DisplayPort Female

Number of monitor

4

HDMI standard

HDMI 2.1

DisplayPort standard

DisplayPort 2.1

Power connector(s)

2 X PCI Express 8 Pin

Design

Cooling type

Active (fansink)

Consumption

330 W

Low profile

No

Format

Dual Slot

Number of PCI slots

2.6

LED

Yes

LED RGB

Yes

Length

330 mm

Width

140 mm

Thickness

57.6 mm

Use

AMD Gamer

Warranties

Commercial warranty

Seller 3 years

Legal warranty

See terms & conditions

Product referenced on 22 Nov 2023

Customer reviews
Global rating
10/10
based on 4 reviews Editorial and moderation guide
  • 100%
    4 reviews
  • 0%
  • 0%
  • 0%
  • 0%
  • by BenoitP
    Posted on 5 Mar 2024
    Product bought from LDLC on 2 Mar 2024
    Number of reviews: 1 Average rating: 10

    At the top!

    25252 in Bench Time Spy (4k) quite honourable.
    No coilwhine (it's a change from my Taichi but that's just chance unfortunately), it's always a pleasure not to have any at all!

    Having had 4080s, 7900 XTXs, etc., I've finally found the symbiosis I've been looking for, the magnificent look of a Gundam edition ;) and sufficient power in 4K and all that for a price well below the average (a small promotional code helped me ahah), in short I highly recommend this card which is well worth the top of the range and which reminds me of a Strix in terms of capacity, yes yes.
    And finally on LDLC is still a + tracking, sending and receiving was clear and faultless, that's what we want ^ ^.

    Thank you LDLC for your services, and Asrock for this superb card :)

    Review automatically translated
  • by EricL
    Posted on 17 Dec 2023
    Product bought from LDLC on 11 Dec 2023
    Number of reviews: 1 Average rating: 10

    Very good

    Hello,
    Very good card for me.
    I know that the Hot Spot on non-custom cards could pose a problem.
    No worries here since on Cyberpunk2077, the Hot Spot reaches 82° (78° in stress test).
    There's no permanent cool whine, but it can happen for 2 seconds before a stress test.
    On TimeSpy , I have a result between 28800 and 29000 points with a fast and stable OC/UV under classic OS with my current programs launched (signalRgB, Icue,msi afterburner etc...) Because to make tests under calibrated OS that does not have interest for me.
    As a reminder, a 4080 Score 28800 average to stock of course.
    In terms of ventilation, the basic curve is set not too badly I think, but I have customised it all the same.
    The card is heavy (1.8kg of memory) so you'll need a support, even if it's very rigid. Your PCIE port will thank you.

    One flaw: I couldn't get Asrock's RGB software to work (or I didn't understand it at all) for the RgB band.
    First of all, of course, I ran a DDU.
    So very satisfied, then at this time (mid-December 2023° A 7900XT CUSTOM AND WHITE at 836Euros, it's Christmas before time

    Review automatically translated
  • by SebastienH
    Posted on 9 Dec 2023
    Product bought from LDLC on 6 Dec 2023
    Number of reviews: 1 Average rating: 10

    A virtually flawless card

    As a replacement for a 6800XT Midnight Black MBA, I was a bit worried about the generation gap, and reading/looking at a lot of tests you end up getting lost.
    I'd recommend the TechPowerUp site, there's a great range, and above all they have nothing to sell...

    To put it bluntly, the gross performance gain over my 6800XT is at least +40%, rising to +80% on certain tests (Time Spy for example, everything else in the configuration is identical)...
    So videos that tell you that the 7900XT is a dud card... let's tell them: lol, Sincerely yours!

    Of course, when you look at the XTX you can clearly see the cuts in the design of the 7900XT, it's called 'range segmentation', and it's generally obvious that the top-of-the-range model is going to be better than the models in the range that precede it.
    Today (12/2023) there is a price gap vs MSRP clearly in favour of the 7900XT, it's a fact we get high quality customs for less than the MBA.

    Even when it comes to RTs, you see everywhere "it's rubbish, they're out of their depth compared to nvidia, it's their big weak point, etc." This isn't untrue, they are factually less good than nvidia's gen 40s, but on the other hand a 7900XT is on a par with a 3090 in RT, or even TI, so I'm not sure you can perfectly well say that it's rubbish :p

    In short, in my opinion, this is a futurproof card for several years to come.

    This model in particular is a pleasure, it's superb (subjective), the lighting effects are very well done, it's huge (see photo) which has to be taken into account when integrating it, and despite the reinforcement it tends to flash a bit at the end, so you need a support.
    I've got a HX1200 and it's right at home, no coil whine or anything else.
    Incredibly quiet and a temperature that doesn't exceed 65° in OC bench mode and with the original curve.
    I'd make the same choice again without hesitation :)

    Review automatically translated
  • by GuillaumeD
    Posted on 5 Dec 2023
    Product bought from LDLC on 26 Nov 2023
    Number of reviews: 9 Average rating: 10

    Formidable

    Product as described
    Delivery on time
    Product really top I am more than satisfied
    I would recommend

    Review automatically translated
