Ekivalan CEPA 19" 20U cabinet depth 600 mm - payload 80 kg - colour black
20U enclosure - dimensions 600 x 600 x 1001 mm - load capacity 80 kg - black - delivered assembled
499€95
Create a price drop alert
1
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
499€95
In stock
Overview
Ideal enclosure for long-term network installations
The ekivalan "CEPA" enclosure is ideal for long-term network installations requiring a high-quality product. Its solid structure allows a load of up to 80 kg, so you can house your patch panels, switches or various 19" rack-mountable active elements without constraint. The ventilation unit (available as an option) can be installed from the inside or the top of the enclosure. It can therefore be accessed without having to remove the 19" components already installed. Each upright is numbered from top to bottom and from bottom to top. This gives you total access. The enclosure is accessible from the front and the sides. You can also add a "Double section" option for access from the rear.
Key features:
- Up to 80 kg payload
- Enclosure can be wheeled (optional)
- Top and bottom cable channels
- Ventilation unit (optional) can be installed without dismantling the 19" units
Main features :
- Rigid structure, width 600 mm and depth 600 mm (riveted, non-removable)
- Height: 20U
- Payload: 80 kg (reduced when used with the double section option)
- Single front door in safety glass, with lock, 235° opening angle
- 2 19" uprights (front) with "U" numbering in 2 directions, depth-adjustable
- 2 removable side panels with lock
- 2 cable channels, top fitted with dust brush (145x70 mm) and bottom (145x70 mm)
- Roof pre-drilled for installation of ventilation unit (optional)
- Protection rating: IP 20
- Complies with EN 61587-1:2012, IEC 297-1 & IEC 297-2, EN 60950-1:2006
- RoHS compliant
- With earthing kit
- Dimensions: 600 x 600 x 1001 mm
- Weight : 32 Kg
- Colour : Black
- 5-year manufacturer's warranty
Logistics information :
This product is available in the following locations: France, Belgium, Luxembourg, Switzerland, Spain, Italy, Monaco.
