Pictures may differ from actual products
ViewSonic LSD400HD
Full HD laser projector - 4000 Lumens - Standard throw - HDMI/USB - 24/7 - 360° orientation - 1 x 15 watts
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
A projector with high brightness
Designed for businesses, educational institutions and golf simulation facilities, the ViewSonic LSD400HD combines 4,000 ANSI lumens of brightness with a Full HD 1080p native resolution. It therefore delivers sharp, legible and detailed presentations, including in large rooms. Its third-generation laser phosphor technology offers up to 30,000 hours of operation in SuperEco mode, while enabling instant start-up and shutdown. Capable of projecting an image up to 300 inches, this lamp-free model is a durable and economical large-format display solution, with energy consumption reduced by up to 59% compared with competing lamp projectors.
3rd gen laser phosphor technology
Brighter, more efficient and 32% more compact than the previous generation, third-generation laser phosphor technology ensures consistent image quality during extended use. The absence of a lamp limits maintenance operations and helps reduce operating costs. The sealed, filter-free optical engine, protected against dust according to the IP6X standard, further enhances the projector's reliability over time.
Up to 300 inches
The DLP projection system, combined with a 0.65-inch Texas Instruments DMD chip, produces deeper blacks, a strong sense of depth and a stated contrast ratio of 3,000,000:1. The LSD400HD reproduces up to 1.07 billion colours and preserves their consistency over time, without yellowing. Its HDMI 2.0b connectivity with HDCP 2.2 also accepts signals up to 4K UHD at 60 Hz as well as HDR10 and HLG content, while displaying them at its Full HD native resolution. A dedicated Golf mode enhances greens and blues in particular to provide a more realistic rendering of virtual courses.
Versatile use
The 1.1x optical zoom, ±30° horizontal and vertical keystone correction and independent four-corner adjustment simplify the process of obtaining a perfectly proportioned image. 360° projection allows the device to be aimed at a wall, ceiling or floor, while the 90° portrait mode opens the way to projection mapping, scenography and advertising displays. Two HDMI inputs, an RS-232 control, an audio output, a 15 W speaker and a powered USB-A port complete this versatile equipment. The latter can notably power the ViewShare WPD-900 wireless kit, available separately.
Main features:
- Laser projector
- Projection technology: DLP, 0.65-inch DMD chip
- Light source: third-generation laser phosphor
- Native resolution: Full HD 1 920 x 1 080 pixels
- Signal compatibility: up to 4K UHD 3 840 x 2 160
- Support: HDR10, HLG and 4K UHD signals at 60 Hz via HDMI 2.0b
- Brightness: 4 000 ANSI lumens
- Contrast ratio: 3 000 000:1
- Colour palette: up to 1.07 billion colours
- Light source lifespan: 20,000 hours in normal mode, up to 30,000 hours in SuperEco mode
- Image size: 30 to 300 inches
- Throw ratio: 1.48 to 1.62
- Projection distance: 0.98 to 10.76 m
- Optical zoom: 1.1x / Digital zoom: 0.8x to 2.0x
- Keystone correction: horizontal and vertical at ±30° / Four-corner adjustment
- 360° projection and 90° portrait mode
- Connectivity: 2 HDMI 2.0/HDCP 2.2, 1 RS-232, 1 USB-A 5 V/1.5 A and 1 3.5 mm audio output
- Built-in speaker: 15 W
- Operating noise: 32 dB in normal mode, 27 dB in Eco mode
- Input lag: 16.7 ms
- Dimensions: 286 x 216 x 129 mm
- Weight: 3 kg
Select your criteria
General information |
Product name |
ViewSonic LSD400HD |
Brand |
ViewSonic | |
Model |
LSD400-HD | |
Main characteristics |
Format |
Office |
Light source |
Laser | |
Technology |
DLP | |
Resolution |
1920 x 1080 pixels | |
4K UHD resolution(s) |
No | |
HDR (High Dynamique Range) |
No | |
Brightness |
4000 Lumens | |
Contrast |
3000000 /1 | |
Gaming |
Gamer |
No |
Lens |
Lens Shift |
No |
Focal type |
Standard throw | |
Min throw ratio |
1.48 | |
Max throw ratio |
1.62 | |
Autofocus |
No | |
Video Signals |
Supported video resolution(s) |
1080p |
| 1080i | ||
| 720p | ||
| 576i | ||
| 576p | ||
| 480p | ||
| 480i | ||
Supported computer science resolution(s) |
3840 x 2160 pixels | |
| 1920 x 1080 pixels | ||
| 640 x 480 pixels | ||
3D compatible |
No | |
Min vertical frequency |
24 Hz | |
Max vertical frequency |
120 Hz | |
Lamp |
Lamp lifespan |
20000 Hour(s) |
Lamp lifespan in Eco mode |
30000 Hour(s) | |
Sound level |
Min sound level |
27 dB |
Max sound level |
32 dB | |
Equipment |
With display |
No |
Remote control |
Yes | |
Sound power |
1 X 15 W | |
Network |
No | |
Smart |
No | |
Android TV |
No | |
Interactive model |
No | |
Connectivity |
Video inputs |
2 X HDMI Female |
HDMI standard |
HDMI 1.4 | |
Audio outputs |
Line OUT (3.5mm Jack Female) | |
Additional connector(s) |
1 X USB Type A Female | |
Physical characteristics |
Width |
286 mm |
Height |
129 mm | |
Depth |
216 mm | |
Weight |
4.5 kg | |
Power supply |
Consumption |
143 W |
Standby consumption |
0.5 W | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
ViewSonic Europe Limited |
Postal address |
Haaksbergweg 75; 1101 BR Amsterdam; The Netherlands | |
Electronic Address |
EPREL@viewsoniceurope.com |
