JBL Club A600
600 W RMS Class D mono amplifier for car subwoofer
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
Power and control for punchy bass
Designed for enthusiasts of demanding car audio, the JBL Club A600 is a mono amplifier dedicated to subwoofers that combines high power, energy efficiency and great adjustment precision. Thanks to its Class D amplification technology, it delivers up to 600 W RMS while limiting electrical consumption and heat build-up, ensuring stable performance even at high volume. Its compact design makes installation easier in many vehicles, including when space is limited. The Club A600 integrates easily into any type of car audio system thanks to its high-level and low-level inputs, enabling compatibility with both factory head units and aftermarket systems. For reproduction perfectly tailored to your setup, it features a variable low-pass filter, adjustable bass boost and a phase switch, offering precise control of bass response. The integration of balanced differential inputs also helps reduce unwanted noise and distortion, ensuring clear, powerful sound. Finally, the wired bass level remote control lets you easily adjust bass intensity from the driver's seat for an immersive, personalized listening experience.
Key features:
- Mono amplifier dedicated to powering an automotive subwoofer enclosure
- High power up to 600 W RMS for powerful, dynamic bass
- Class D technology ensuring high efficiency and low consumption
- Compact format for easy installation in most vehicles
- High-level and low-level inputs compatible with factory and aftermarket head units
- Variable low-pass filter and adjustable bass boost for precise bass tuning
- Phase switch to optimize subwoofer integration in the vehicle
- Wired bass level remote control for quick adjustment from the cabin
- Low-noise, low-distortion design thanks to balanced differential inputs
- Built-in electronic protections against short circuits, overvoltage and overheating
Main specifications:
- Mono amplifier for automotive subwoofer
- Amplification class: Class D
- RMS power: 600 W x1 into 2 Ω
- RMS power: 350 W x1 into 4 Ω
- Frequency response: 10 Hz – 320 Hz
- Low-pass filter: 32 – 320 Hz, 12 dB/octave slope
- Bass boost: 0 to 12 dB at 45 Hz
- Phase switch: 0° / 180°
- Input sensitivity: 2 V – 20 V
- Signal-to-noise ratio: > 80 dB
- Distortion (THD+N): < 1 %
- Audio inputs: RCA and speaker-level
- Bass level remote control: included (RBC)
- Fuses: 2 x 30 A
- Power supply voltage: 9 – 16 V
- Dimensions (W x H x D): 220 x 51,3 x 180 mm
- Weight : 2,5 kg
- Color: Black
- 1 x Club A600 mono amplifier for car subwoofer
- 4 30 A ATO fuses (2 installed, 2 spare)
- 2 RCA adapters for bare wires
- 1 x remote bass control module
- 1 remote control cable (RJ-25 connectors on both ends)
- 2 x self-tapping screws for remote control (M3 x 15 mm)
- 4 mounting screws (M4 x 53 mm)
- 2 JBL stickers
- 1 x Owner’s Manual
Select your criteria
General information |
Product name |
JBL Club A600 |
Brand |
JBL | |
Model |
AMPCBA600 | |
Technical specifications |
Number of channels |
1 |
Admissible power |
350 W | |
Maximum power |
600 W | |
Réponse en fréquence (min) |
32 Hz | |
Frequency response (max) |
320 kHz | |
Sensitivity (for 1W at 1m) |
12 dB | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
