Blackmagic Design ATEM Mini Extreme ISO G2
Production switcher for streaming with 8 HDMI inputs + 2 integrated audio channels
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
For easier-than-ever live streaming
The Blackmagic Design ATEM Mini Extreme ISO G2 is a powerful and compact live switcher, ideal for creating a high-end broadcast studio. Features an extensive control panel, 8 HDMI inputs with standards conversion, 3 HDMI outputs, multi view, streaming engine, and CFexpress and Thunderbolt compatibility for recording and playback. It also includes a 10G Ethernet port for fast access to network storage, XLR audio inputs, USB webcam output, DVE, chroma keying, media player and ISO recording of all 8 video inputs.
Features :
- Second-generation all-in-one broadcast switcher by Blackmagic
- Allows recording directly to USB disks in H.264 and live streaming
- All mixer functions can be accessed from the front panel
- Connect up to 8 cameras, games consoles or computers via 8 HDMI ports
- Numerous creative options thanks to professional transitions
- HD video input standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
- HD video output standards: 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
- Total number of video inputs: 9
- Total number of outputs: 4
- Total number of auxiliary outputs: 4
- SDI bit rates: 1.5G, 3G
- HDMI video inputs: 8 x HDMI Type A, switchable to 10-bit HD.
- 2 integrated audio channels.
- HDMI video outputs: 3
- HDMI programme outputs: 3
- Total audio inputs: 2 x XLR combined with phantom power / 1 x BNC 32-channel digital audio MADI.
- Total audio outputs: 1 x 6.35 mm headphone jack
- Synchronisation of video inputs to 8 HDMI inputs and remote sources
- Frame rate and format converters on 8 HDMI inputs and remote sources
- Webcam output: 2 x USB-C supporting 720p or 1080p at PGM frame rate.
- Number of multi views: 1
- 1 x 1G Ethernet for simple streaming, control panels and Internet connection
- 1 x 10G Ethernet connection for recording.
- 2 x USB Type-C 3.1 Gen 1 connectors for external disk recording, webcam output, software control, software updates and panel connection.
- 1 x Thunderbolt for fill and key output, video input, Ethernet connection to storage and power.
- DaVinci Resolve project file
Select your criteria
General information |
Product name |
Blackmagic Design ATEM Mini Extreme ISO G2 |
Brand |
Blackmagic Design | |
Model |
SWATEMMINICEXTISOG2 | |
Technical specifications |
Accessory type |
Deck / Controller |
Compatibility |
Mac OS X | |
| Microsoft Windows 10 | ||
Length |
414 mm | |
Width |
186.8 mm | |
Height |
50 mm | |
Weight |
1.85 kg | |
Warranties |
Commercial warranty |
Seller 2 years
|
Legal warranty |
See terms & conditions
|
|
Safety Information |
Responsible person |
Blackmagic Design Europe B.V |
Postal address |
Fascinatio Boulevard 216, 3065 WB Rotterdam, Pays-Bas | |
Electronic Address |
Click here
|
Product referenced on 7 Nov 2025
For the moment, there are no customer reviews.Write a review
